Food Waste for Solar Storage
Dec 29, 2016
by Michael Abrams ASME.org
Solar energy still has a problem. Storage. Batteries are nice, but there are losses going to and from chemical storage. Water tanks can help use the light of day to warm our nights, but they don’t hold on to their heat for the long term.
To turn the heat from our summer sun to heat for our winters we may soon be able to turn to our leftovers. There’s no dearth of the stuff. Some 40 percent of U.S. food ends up in the trash, of which 97 percent winds up in a landfill. That’s 33 million tons per year, if you prefer your stats by weight.
There’s gold in those hills of rotting comestibles, in the form of sugar alcohols. They have a high storage capacity, they’re safe, and thanks to our wastefulness, they’re plentiful. “The major problem with using sugar alcohols as heat storage is they are quite slow in terms of its heat transfer kinetics,” says Huaichen Zhang, a mechanical engineer at the Netherlands’ Eindhoven University of Technology. Now Zhang may have found a way to fix that problem.
Where the heat conductivity of sugar alcohols is below one Calvin per watt per meter, the heat conductivity of nanoscale carbon structures, like graphene or carbon nanotubes, is a thousand watts per meter per Calvin. “What if you mix them up?” asks Zhang. “What if you combine them, make a sort of composite material? How can it improve the heat conductivity?”
To answer the question, Zhang ran a molecular-scale simulation, using molecular dynamics modeling methods, to see exactly how the heat transferred from the carbon to the sugar alcohols and vice versa. In 2015, he examined two possible mechanisms. The first, heating the carbon layer with a laser beam, proved too slow to produce any real advantage. The second is more promising: transferring heat from sugar alcohol to sugar alcohol, using the carbon as a sort of heat transfer medium. “So the heat passes through it, instead of transferring into it and out of it again,” says Zhang.
Using this mechanism, Zhang showed that when mixed with erythritol and xylitol, two sugar alcohols commonly found in food, carbon nanotubes with larger diameters were better at conducting heat. Higher density combos also improved head conductivity.
That’s great for getting the heat locked up in the sugar alcohols. But when the time comes to use that heat, we don’t yet know how to get it quickly. “It seems that the higher the storage energy density is, the harder it is to get the energy out,” says Zhang. “These are the major problems we want to solve: To increase the crystal growth speed, to increase the heat power, and the discharge power, so we can get the heat out as fast as possible, and as much as possible and whenever we want it. Currently we don’t know how to do it.”
Though that may sound like a full plate of research, Zhang thinks those problems are eminently solvable and that a real-world application will be available in a not-too-distant future.
“Actually it’s not that far off, if you just want the material,” he says. “To commercialize it, we have a ways to go.”
Michael Abrams is an independent writer.
Learn more about the latest energy technologies atASME's Power and Energy.
The major problem with using sugar alcohols as heat storage is they are quite slow in terms of its heat transfer kinetics.Huaichen Zhang, Eindhoven University of Technology
