Flow-Induced Vibration with Applications to Failure Analysis (Virtual Classroom)

Learn and apply the latest design and analysis tools for the prediction and prevention of vibration in structures exposed to high energy fluid flow.

This Standard was last reviewed and reaffirmed in {{activeProduct.ReaffirmationYear}}. Therefore this version remains in effect.

Flow-Induced Vibration with Applications to Failure Analysis (Virtual Classroom)
{{ onlyLocationDate }}
{{ errorMessage }}

Final invoices will include applicable sales and use tax.

Print or Share

Course Options

  • Location and Date
    Available Seats
    Price
    List Price
    Member Price
  • Dec 06-08th, 2021

    Sold Out

    $1395
    $1395
    $1395
    Select
    Selected
Description

Package Items
Quantity Item
{{ package.Quantity }} {{ package.Title }}

Enroll now to save 34%

$2,110 $1,395

ASME’s Combo Course Packages are curated groupings of our most popular live courses across a common topic, use case, or industry. Enroll in the ASME BPVC Section III: N-1300 Applied Design, Failure Analysis and Prevention of Shock and Vibration Combo Course  and save $595.

Course Schedule:  The course runs from 9:30 AM to 1:30 PM and 2:00 PM to 6:00 PM Eastern, each day, with scheduled breaks throughout.

Problem-solving methodologies are the main focus of this comprehensive course on practical applications of flow and vibration theory. The latest design and analysis tools for the prediction and prevention of vibration in structures exposed to high energy fluid flow are covered in practical detail.

This comprehensive course reviews fundamentals of flow and vibration theory. Attendees benefit from the problem-solving activities at the conclusion of each section. Topics such as vortex and turbulence induced vibration, galloping, flutter, sonic fatigue and fluid-elastic instability will be covered in-depth. Attendees are introduced to state-of-the-art analysis tools for the prediction and prevention of vibration in structures exposed to high-energy fluid flow. Case studies and a workshop create an interactive course that aid engineers at various levels.

You Will Learn to:

  • Explain the vortex-induced vibration, galloping, flutter, sonic fatigue, and fluid elastic instability
  • Describe the latest Vibration theory and ASME B&PV Code, Section III: N-1300 on Flow-Induced Vibration
  • Describe the analysis and test techniques in conjunction with strategies for successful design
  • Evaluate examples of heat exchanger vibration, strumming of cables, and vibration and fatigue of pipes and panels
  • Analyze the root cause of the Tacoma Narrows Bridge Collapse
  • Determine how the flow-induced tube vibrations caused the shutdown at the San Onofre Nuclear Generating station.

Who Should Attend
Engineers in the following fields are strongly encouraged to attend: design, mechanical, product development, system, R&D, noise, maintenance, and diagnostics. Supervisors and managers responsible for the economic impact of flow-induced component damage will also greatly benefit from the course content.

Course Materials (included in the price of the course)
Participants receive a downloadble version of the course presentation via the Learning Management System and receive copies of Flow-Induced Vibration, 2nd Edition, by Dr. Robert Blevins.

Please note that registration may close up to 10 days prior to the start of the course to ensure that attendees receive the book in a timely manner.

This ASME Virtual Classroom course is held live with an instructor on our online learning platform.
Certificate of completion will be issued to registrants who successfully attend and complete the course.

Buying for a team? Get ASME Corporate Training.

Set up a customized session of this course for your workforce. Contact learningsolutions@asme.org to learn more about group rates.

Expand
Outline

Topics Covered

  • Introduction to Flow-Induced Vibration
  • Dimensional analysis in fluid-structure interaction
    • Theoretical and experimental approaches to Flow-Induced Vibration analysis
    • Dimensional analysis and model scaling
    • Application to motions of a tall building in wind
  • Natural Frequencies of Fluid and Structures
    • Single degree of freedom
    • Multi degree of freedom
    • Natural frequencies of Beams, plates and shells
  • Forced Vibration
    • One degree of freedom spring-mass systems
    • Vibration of continuous structures:
      • Beams, plates, and shells
    • Damping and damper design
  • Fluid Forces on Structures
    • Drag and added mass of structures in flow
    • Pressure and shear drag, drag coefficients, forces on cylinder in a wake
    • Added mass and coupling between structures in water and dense fluids
  • Vortices and Vortex Shedding from Stationary Structures
    • Strouhal numbers and the vortex street
    • Reynolds number effects
  • Vortex Shedding from Vibrating Structures
    • Lock in and lift coefficients
    • Feedback and the motion induced changes in vortex shedding
  • Prediction of Vortex-Induced Motion of Cylinder in a Flow
    • Coupled response
    • Application to stacks and offshore structures
  • Reduction of Vortex-Induced Vibration in Air and Water
    • Design of strakes and dampers
  • Galloping and Flutter
    • Lift and torsion on in inclined airfoils, and rectangular bodies
    • Divergence in a steady wind
    • Galloping an mixed mode phenomena
    • Application to bridge decks and vanes
  • Heat Exchanger Tube Flow-Induced Vibration
    • Tube and shell heat exchanger design and fluid dynamics
    • Fluid Forces on clusters of tubes
    • Onset of instability and tube wear
    • Application to heat exchangers in chemical and nuclear power industry
  • Aeroacoustics: Sound Generation by Flow
    • Free propagation
      • Ray acoustics, SPL, and dB
    • Traveling and stationary acoustic waves in ducts and cavities
    • Heat exchanger acoustic resonance
    • Flow excitation of cavities
  • Vibration Due to Internal Flow
    • Sources of acoustic energy in ducts and piping systems
    • Transmission of sound and turbulence
    • Case histories of internal flow induced vibration
    • Reduction of sound in piping
    • Thermal-acoustic excitation and internal flow instability
  • Turbulence-Induced Vibration and Buffeting
    • Application of random vibration theory to turbulence
      • Calculation of spectra and structural response
    • Models for turbulence in practical systems
    • Application to process and power plants and in aerospace
Expand
Instructor

Dr. Robert D. Blevins has over 30 years of experience in flow-induced vibration. He is a member of the ASME Special Working Group on Structural Dynamics and the Pressure Vessel Research Council's Committee on Dynamic Analysis of Pressure Components. He received a Ph.D. (1974) from the California Institute of Technology. He worked on flow induced vibration of Reactors at General Atomics and was a Fellow at United Technologies for Dynamics and Vibration. He has consulted for numerous government and industrial clients on fluid flow and vibration. Dr. Blevins has written four books and fifty papers. He has taught for ASME for over 20 years.
